- 外形图
-
Electrical & Mechanical Specifications
Part No.
83092
Type
2-WayPower
Splitter
3-WayPower
Splitter
4-WayPower
Splitter
Frequence(MHz)
380-3800
380-3800
380-3800
Split Loss ≤3
≤4.8
≤6.0
Insertion loss
≤0.3 dB
≤0.4 dB
≤0.5 dB
VSWR
≤1.25
Intermodulation
≤150/155/160dBc (with 2×20W)
Impedance
50 Ω
Input power
≤300W (avg.)
Operating temperature
-25°C to +75°C
Storage temperature
-40°C to +85°C
Relative 5% - 95%
Application
Outdoor (IP65) Connector Type
N Female /4.3-10 Female/DIN Female
Typical Attenuation Curves
Schematic diagram
Type Part No. Weight（kg） Dimensions（mm） Connectors 2-Way
8309222
≤0.45
193*25*25
DIN- Female
2-Way
8309221
≤0.43
193*25*25
4.3-10- Female
2-Way
8309223
≤0.43
193*25*25
N- Female
3-Way
8309232
≤0.52
229*25*25
DIN- Female
3-Way
8309281
≤0.50
229*25*25
4.3-10- Female
3-Way
8309233
≤0.50
229*25*25
N- Female
4-Way
8309242
≤0.57
236*25*25
DIN- Female
4-Way
8309241
≤0.55
236*25*25
4.3-10- Female
4-Way
8309243
≤0.55
236*25*25
N- Female
Packaging information
Item
Specifications(mm) PCS
Inner box
Outer box
Qty of products
Weight(kg)
Inner box
290*180*100
1 /
/
1 0.6 Outer box
398*295*235
1 30
/
30
19 Transport
1000*1200*1600
1 900
30 900
600 -
测试规范
测试项目
SPL
互调分析仪
LOT
网络分析仪 ☑常温指标
☑
Kaelus IQA-0703C (758-803)
□
☑Agilent E5071C
☑低温指数
☑
Kaelus IBA-0790B(791-821)
□
□Agilent E5061B
☑高温指数
☑
Kaelus IQA-0901C(925-960)
☑
□Agilent E5063A
☑模拟振动测试
☑
Kaelus IQA-1800C(1805-1880)
☑
□Agilent E5071B 四通道
☑电源测试
☑
Kaelus IQA-21001C(2110-2170)
□
/ ☑盐雾测试
☑
PIMTEK 2600SBT(2620-2690)
☑
Agilent calibrator
☑雨水测试
☑
PIMTEK 800S(869-894)
□
☑machinery 80532F
☑互调测试
☑
PIMTEK 1900SBT(1930-1990)
□
□machinery 85033E
☑气密性测试
/ □machinery 85054D
☑目检
/ □Electron N4431B
-
