Main Features
• Double units for easy use with XPol antennas
•Support AISG 2.0
• Suitable for antenna RET control according to AISG/3GPP
•Built-in lightning protection
规格 Specifications
Part No.
8620554
RX
Frequency Range
75 MHz (1710 MHz to 1785 MHz)
60MHz (1920 MHz to1980 MHz)
Gain
12dB±1dB
12dB±1dB
Gain Fluctuation @25℃
1.5dB max
1.5dB max
Noise Figure @25℃
1.6dB typ 1.85dB max
1.55dB typ 1.75dB max
Return loss in normal mode
18dB min
18dB min
Max input power
<12dBm
<12dBm
Output 1dB compression
>12dBm
>12dBm
Insert loss in by-pass mode @25℃
2.5dB typ., 2.8dB max
2.4dB typ., 2.7dB max
TX
Frequency Range(MHz)
75 MHz (1805 MHz to 1880 MHz)
60 MHz (2110 MHz to 2170 MHz)
Insert loss @25℃
0.50dB typ.,0.60dB max
0.30dB typ.,0.50dB max
Average power
180W
180W
Peak power
1.6KW
1.6KW
Intermodulation products in RX band
(2TX carriers at +43 dBm)
≤-160dBc(Power up)@ANT IM3
≤-160dBc(Power up)@ ANT IM7
≤-150dBc(Power up)@BTS IM3
≤-150dBc(Power up)@BTS IM7
Environmental Characteristics
Operating temperature range
–40~ +65 °C
IP rating
IP67
MTBF
> 1,000,000 hours (per TMA)
EMC
According to ETS 300 342-3
DC and alarm characteristics
AISG Mode
DC Supply
10–30 V
Mechanical Characteristics
RF connectors
DIN 7-16（F）*4 long neck
8-pin female，IEC 60130-9
（pin 3:RS485B，pin 5:RS485A，
pin 1 and pin 6：10–30V DC，pin 7：DC return，other pins：not connected）Mounting
Wall mounting：with 4 screws（max. 8 mm diameter），mast mounting：with additional clamp set Weight
Approach 11kg
Dimensions (W*H*D)
225x290x139mm(Without connectors，without mounting brackets)
原理图 Schematic diagram
附件 Accessories
包装信息 Packaging information
物品
规格(mm) PCS
内盒
外箱
产品数量
重量(kg)
内盒
292.5*145*485
1 - - 1 11
外箱
600*500*315
1 4 - 4 44 运输
1000*1200*1380
1 64 16 64 720
-
测试规范
测试项目
SPL
互调分析仪
LOT
网络分析仪 ☑常温指标
☑ Kaelus IQA-0703C (758-803)
□
☑Agilent E5071C
☑低温指数
☑ Kaelus IBA-0790B(791-821)
□
□Agilent E5061B
☑高温指数
☑
Kaelus IQA-0901C(925-960)
□ □Agilent E5063A
☑模拟振动测试
☑ Kaelus IQA-1800C(1805-1880)
☑ □Agilent E5071B 四通道
☑电源测试
☑ Kaelus IQA-21001C(2110-2170)
☑ / ☑盐雾测试
☑ PIMTEK 2600SBT(2620-2690)
□ Agilent calibrator
☑雨水测试
☑ PIMTEK 800S(869-894)
□ ☑machinery 80532F
☑互调测试
☑ PIMTEK 1900SBT(1930-1990)
□ □machinery 85033E
☑气密性测试
/ □machinery 85054D
☑目检
/ □Electron N4431B
-
