规格
Part No.
8620354
RX
Frequency Range(MHz)
15MHz (824 MHz to 839 MHz)
10 MHz (905 MHz to 915 MHz)
Gain
12dB±1dB
Gain Fluctuation
±0.4dB typ., ±0.8dB max
Noise Figure
1.8dB typ.
Group Delay
45 ns max over any 5MHz in Rx band
Return loss in by-pass mode
14dB min
Return loss in normal mode
18dB min
Max Input Power
<12dBm
Output 1dB compression
>12dBm
Output IP3(OIP3)
>25dBm
Insert loss in by-pass mode
2.2dB typ.
Impedance
50Ω
TX
Frequency Range(MHZ)
15 MHz (869 MHz to 884 MHz)
10 MHz (950 MHz to 960 MHz)
Insert loss
0.60dB typ.
Return loss
18dB min
Group Delay
45 ns max over any 5MHz in Rx band
Average Power
200W
Max Power
2.5KW
Intermodulation products in RX band
<-107dBm (2 Tx carriers at +43 dBm) (Power up)
Environmental Characteristics
Operating temperature range
-40~+55℃
IP rating
IP 67
MTBF
> 1 000 000 hours (per TMA)
EMC
According to ETS 300 342-3
DC and Alarm Characteristics
AISG Mode
DC supply
10–30 V
Operating current per TMA
(without RET)
Nom. 280 mA at 10 V
Nom. 110 mA at 30V
Alarm management
AISG
Mechanical Characteristics
Material
铝制外壳 Aluminium housing Connectors RF
AISG
DIN 7-16（F）*4 long neck
8-pin female，IEC 60130-9
（pin 3:RS485B，pin 5:RS485A，
pin 1 and pin 6：10–30V DC，pin 7：DC return，other pins：not connected）Mounting
壁装：带4个螺钉(最大直径8mm) Wall mounting: with 4 screws (max. 8 mm diameter)
抱杆安装：配喉箍 Mast mounting: with additional clamp set
Weight
<11kg
Dimensions
290x225x139mm（无连接器，无安装支架） 原理图
附件
包装信息
物品
规格（mm） PCS
内盒
外箱
产品数量
重量(kg)
内盒
292.5*145*485
1 - - 1 11
外箱
600*500*315
1 4 - 4 44 运输
1000*1200*1380
1 64 16 64 740
-
测试规范
测试项目
SPL
互调分析仪
LOT
网络分析仪 ☑常温指标
☑ Kaelus IQA-0703C (758-803)
□
☑Agilent E5071C
☑低温指数
☑ Kaelus IBA-0790B(791-821)
□
□Agilent E5061B
☑高温指数
☑
Kaelus IQA-0901C(925-960)
□ □Agilent E5063A
☑模拟振动测试
☑ Kaelus IQA-1800C(1805-1880)
☑ □Agilent E5071B 四通道
☑电源测试
☑ Kaelus IQA-21001C(2110-2170)
☑ / ☑盐雾测试
☑ PIMTEK 2600SBT(2620-2690)
□ Agilent calibrator
☑雨水测试
☑ PIMTEK 800S(869-894)
□ ☑machinery 80532F
☑互调测试
☑ PIMTEK 1900SBT(1930-1990)
□ □machinery 85033E
☑气密性测试
/ □machinery 85054D
☑目检
/ □Electron N4431B
-
