主要特点 Main Features
•Double units for easy use with XPol antennas
•Support AISG 2.0
•Suitable for antenna RET control according to AISG/3GPP standard
•By-pass mode to ensure cell operation in case of DC power down
•Built-in lightning protection
规格
Part No.
8620754
RX
Frequency(MHz)
905-915MHz
824-839MHz
Band width
10MHz
15MHz
Gain Default
12dB±1dB
12dB±1dB
Gain Fluctuation
0.6dB typ., 1.2dB max
0.6dB typ., 1.2dB max
Noise Figure
1.50dB typ.,1.9dB max
1.60dB typ.,1.80dB max
Return loss in by-pass mode
14dB min
14dB min
Return loss in normal mode
18dB min
18dB min
Max Input Power
<12dBm
<12dBm
Output 1 –dB compression pint
12dBm min
12dBm min
Output IP3
25dBm min
25dBm min
Insert loss in by-pass mode
2.0dB typ., 2.25dB max
2.1dB typ., 2.5dB max
Impedance
50Ω
50Ω
TX
Frequency Range(MHZ)
950-960MHz
869-884MHz
Band width
10MHz
15MHz
Insert loss
0.50dB typ.,0.70dB max
0.45dB typ.,0.65dB max
Intermodulation products in RX band
<-107dBm (2 Tx carriers at +43 dBm) (Power up) @BTS
<-107dBm (2 Tx carriers at +43 dBm) (Power up) @BTS
Return loss
18dB min
Average power
180W
Peak Power
1.6KW
Environmental Characteristics
Operating temperature
0~ +55 °C
Relative humidity
5 to 95%
IP rating
Indoor or outdoor (IP67)
MTBF
> 1 000 000 hours (per TMA)
EMC
According to ETS 300 342-3
DC and Alarm Characteristics
AISG mode
DC supply
10– 30 V
Operating current per TMA
(without RET)
Nom. 280mA at 10 V, Nom. 110 mA at 30V
Alarm management
AISG mode
Mechanical Characteristics
Material
铝制外壳 Aluminium housing Connectors RF
AISG
DIN 7-16(F)*4 long neck
8pin female，IEC 60130-9
(pin 3:RS485B，pin 5:RS485A，
pin 1 and pin 6：10–30V DC，pin 7：DC return，other pins：not connected)
Mounting
壁装：带4个螺钉(最大直径8 mm) Wall mounting: with 4 screws (max. 8 mm diameter)
抱杆安装：配喉箍 Mast mounting: with additional clamp set
Weight
<11kg
Dimensions
290x225x139mm（无连接器，无安装支架） 原理图
附件
包装信息
物品
规格（mm） PCS
内盒
外箱
产品数量
重量(kg)
内盒
292.5*145*485
1 - - 1 11
外箱
600*500*315
1 4 - 4 44 运输
1000*1200*1380
1 64 16 64 740
-
测试规范
测试项目
SPL
互调分析仪
LOT
网络分析仪 ☑常温指标
☑ Kaelus IQA-0703C (758-803)
□
☑Agilent E5071C
☑低温指数
☑ Kaelus IBA-0790B(791-821)
□
□Agilent E5061B
☑高温指数
☑
Kaelus IQA-0901C(925-960)
□ □Agilent E5063A
☑模拟振动测试
☑ Kaelus IQA-1800C(1805-1880)
☑ □Agilent E5071B 四通道
☑电源测试
☑ Kaelus IQA-21001C(2110-2170)
☑ / ☑盐雾测试
☑ PIMTEK 2600SBT(2620-2690)
□ Agilent calibrator
☑雨水测试
☑ PIMTEK 800S(869-894)
□ ☑machinery 80532F
☑互调测试
☑ PIMTEK 1900SBT(1930-1990)
□ □machinery 85033E
☑气密性测试
/ □machinery 85054D
☑目检
/ □Electron N4431B
-
